Operating Table OT80.25
Inspital operating tables, featuring powerful and stable electro-hydraulic systems, meet all critical requirements of modern operating rooms. A wide range of accessories ensures high flexibility across various surgical disciplines.
This operating table is equipped with a reliable battery backup system, enabling up to 20 full movements or 1 hour of continuous operation. Upon request, durable and antibacterial PUR or visco cushions, as well as a body bridge, are available.
Our experts are ready to offer you the most suitable solutions.
General Features
- Quick-Release Mechanism
- User-Friendly Design
- Secure Fit
- Improved Maneuverability
- Enhanced Durability
- Central Locking System
Technical Specifications
| Technical Specifications | |
|---|---|
| Model | OT80.25 |
| Sliding Movement | 300 mm |
| Lateral Tilt Movement | +20° / -20° |
| Back Rest Movement | +80° / -45° |
| Reverse Trendelenburg / Trendelenburg | -30° / +30° |
| Leg Rest Up / Down | +50° / -90° |
| Head Rest Movement | +30° / -50° |
| Flex / Reflex Position | +225° / -100° |
| Width x Length | 560 x 2200 mm |
| Height | 595 - 1035 mm |
| Mattress Thickness | 70 mm |
| Castors Diameter | Ø 125 mm |
| Maximales Patientengewicht | 454 kg / 1000 lbs |
| Kidney Bridge | 140° (optional) |
| Visco Padding | Optional, OT80.25V |
| MOVEMENT | |
|---|---|
| Height | Electro-hydraulic |
| Back Rest | Electro-hydraulic |
| Trendelenburg | Electro-hydraulic |
| Lateral Tilt | Electro-hydraulic |
| Sliding | Electro-hydraulic |
| Central Locking | Electro-hydraulic |
| Head Rest | Manual |
| Leg Rests, Up / Down | Manual |
Downloads
The Highlights.
Kidney Bridge (Optional)
The integrated kidney bridge is adjustable up to 140° (165 mm) and allows for optimal positioning for corresponding surgical procedures.
Longitudinal Shift Function
The 300 mm long longitudinal shift allows easy access for X-ray imaging without disturbing the sterile environment.
Functional Design
The in-hospital operating tables are designed to easily adapt to various surgical procedures and optimally meet the respective requirements.
Multiple Control Units
• User-friendly hand and column controls
• 7 adjustable functions, including braking system
• 7 adjustable functions, including braking system
T-Base
The T-base provides optimal access for the surgical team and OR equipment. The corrosion-resistant stainless steel design ensures durability and reliability in demanding OR environments.
Ideal Access for C-Arms
The radiolucent tabletop enables high-quality imaging in all areas and facilitates access for the C-arm.
Ideal Mattress Performance
The padded mattresses are developed and manufactured according to pressure distribution technology test results to ensure optimal comfort and pressure relief.
