VK40.16

Vacuum Pumps

The lubricated rotary vane pumps are designed to be used in a wide range of industrial and healthcare applications. They can run continuously from atmospheric pressure to ultimate vacuum.

Our experts are ready to offer you the most suitable solutions.

Get an Offer

Specially designed for medical applications
Stable and longlife pumps
Lubricated rotary vane vacuum pumps
Single stage vacuum pump
High pumping speed even at low pressure
Integrated oil mist filter on the exhaust
Pumps can run continuously from atmospheric pressure to ultimate vacuum
Silent and very robust pumps
Options; Oil level switch, PT100 temperature sensor

Maintenance Kits
Usual maintenance (EC) : 3 000 hours or 24 months

Inspection / cleaning
Oil change
Oil filter replacement
Oil separating cartridge(s) change
Inlet valve overhaul
Gas ballast filter change

Maintenance Kits
Preventive maintenance (MP): 12 000 hours

Radial shaft seals change
Sliding rings change
Vanes replacement*
End cover gaskets replacement
Automatic drain + gaskets replacement
Rubber feet replacement
Coupling ring overhaul

Model No	Nominal Flow		Motor Power		Weight	3 000 Hours or 24 months, Maintenance Kits	12 000 hours Maintenance Kits
	m³.h-¹		Kw		Weight	3 000 Hours or 24 months, Maintenance Kits	12 000 hours Maintenance Kits
	50 Hz	60 Hz	50 Hz	60 Hz	kg	Model No	Model No
VK40.16	30	35.3	0,75	0,9	39	VK40.46	VK40.56
VK40.17	47.7	56	1,1	1,32	52	VK40.46	VK40.56
VK40.18	64.3	72.2	1,5	1,8	75	VK40.48	VK40.58
VK40.19	96	115	2,2	2,70	85	VK40.49	VK40.59
VK40.20	132	156	3	3,6	154	VK40.50	VK40.60
VK40.21	198	240	4	4,8	140	VK40.51	VK40.61
VK40.22	293	354	5,5	6,6	162	VK40.52	VK40.62
