GZ80.20

Medical Compressed Air

Medical Compressed air is a widely used gas in hospitals. Therefore, the requirements and quality
standards are high. Medical compressed air is important for the ventilation of ICU patient. It is the most
important medical gas other than oxygen. International standards such as EN ISO 7396-1 and the European Pharmacopoeia guarantee the continuity of medical compressed air and ensure that quality control is carried out regularly. In addition, it defines the limit values that the medical air must have. With INSPITAL Medical Compressed Air Stations, we ensure that you obtain quality air according to EN ISO 7396-1 and European Pharmacopoeia.

Our experts are ready to offer you the most suitable solutions.

Get an Offer

Contamination	European Pharmacopoeia
O2	20.4%
CO2	<500 ppm
CO	<5 ppm
SO2	<1 ppm
NO	<2 ppm
NO2	<2 ppm
H2O	<67 ppm
Oil vapor	<0.1 mg/m3

Model No	Compressor Capacity	Compressor Pcs	Compressor Type	Tank Capacity	Filtration and Dryer System	Operating Temperature	Bed Quantitiy
GZ80.20	3x 39 m³/h	3	Screw Type	2x300 L	2	(+10) - (+50) C°	50-100
GZ80.21	3x 57 m3/h	3	Screw Type	2x500 L	2	(+10) - (+50) C°	100-150
GZ80.22	3x84 m3/h	3	Screw Type	2x1000 L	2	(+10) - (+50) C°	150-200
GZ80.23	3x117 m3/h	3	Screw Type	2x1000 L	2	(+10) - (+50) C°	200-250
GZ80.24	3x138 m3/h	3	Screw Type	2x1500 L	2	(+10) - (+50) C°	250-300
GZ80.25	3x210 m3/h	3	Screw Type	2x2000 L	2	(+10) - (+50) C°	300-500
GZ80.26	3x260 m3/h	3	Screw Type	2x2000 L	2	(+10) - (+50) C°	300-500
